Model | BSM275M-60 | BSM280M-60 | BSM285M-60 | BSM290M-60 | BSM295M-60 | ||||
Rated Maximum Power at STC | 275W | 280W | 285W | 290W | 295W | ||||
Open CircuitVoltage(Voc/V) | 38.86 | 39.05 | 39.25 | 39.46 | 39.64 | ||||
Maximum Power Voltage(Vmp/V) | 31.51 | 31.86 | 31.85 | 32.07 | 32.29 | ||||
Short Circuit Current(Isc/A) | 9.27 | 9.36 | 9.45 | 9.56 | 9.67 | ||||
Maximum Power Current(Imp/A) | 8.72 | 8.84 | 8.97 | 9.11 | 9.23 | ||||
Module Efficiency(%) | 16.82 | 17.12 | 17.43 | 17.74 | 18.04 | ||||
Power Tolerance | -0~+5W | ||||||||
Standard Test Condition(STC) | Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5 | ||||||||
Solar Cell | Mono 156*156mm | ||||||||
Panel Dimensions | 1640*992*35mm | ||||||||
Front Cover | 3.2mm High transmission, low Iron | ||||||||
Frame | Anodized Aluminium Alloy | ||||||||
Panel Efficiency | 18.44% |
